| Device Type | Switch – 24 Ports – L3 – Managed – Stackable |
|---|---|
| Enclosure Type | Rack-mountable (1U) |
| Subtype | Gigabit Ethernet |
| Ports |
24 × 10/100/1000 (PoE) 4 × Gigabit SFP (uplink) |
| Power Over Ethernet (PoE) | PoE |
| PoE Budget | 370 W |
| Performance |
Throughput: 41.7 Mpps Switching capacity: 56 Gbps Latency (1 Gbps): 3.8 µs |
| Capacity |
Jumbo frame size: 9220 bytes IPv4 routing table: 10,000 entries IPv6 routing table: 5,000 entries |
| MAC Address Table | 32K entries |
| Routing Protocols |
OSPF, OSPFv2, OSPFv3 RIP, RIP-1, RIP-2, RIPng BGP IGMPv2, IGMPv3, MLD Static IPv4 & IPv6 routing CIDR |
| Remote Management Protocols |
SNMP (v1, v2, v2c, v3) RMON, XRMON Telnet SSH, SSH-2 CLI |
| Encryption Algorithms | MD5, SSL |
| Authentication Methods | RADIUS, PAP, CHAP, TACACS, TACACS+ |
| Features |
Flow control, full-duplex DHCP & BOOTP support ARP support VLAN support IGMP snooping Syslog DiffServ, QoS, CoS, ToS IPv6 support SNTP sFlow STP, MSTP, Root Guard LLDP LACP ACL support Jumbo frames DHCP server UDLD MIB I/II MAC lockout Dynamic ARP protection DHCP protection Dynamic VLAN (GVRP/MVRP) NDP OpenFlow support CPU protection ICMP & IRDP VXLAN |
| Compliant Standards |
IEEE 802.1D, 802.1Q, 802.1p IEEE 802.3af, 802.3at, 802.3x IEEE 802.3ad (LACP) IEEE 802.1w, 802.1x, 802.1s IEEE 802.1ad, 802.1v IEEE 802.1ab (LLDP) IEEE 802.3az IEEE 802.1AX |
| Processor | ARM Cortex-A9 (1.016 GHz) |
| RAM | 1 GB DDR3 SDRAM |
| Flash Memory | 4 GB |
| Interfaces |
24 × 1000Base-T RJ-45 (PoE) 4 × Gigabit SFP 1 × serial console |
| Expansion Slots | 1 total / 1 free |
| Installed Modules (Max) | 0 installed / 4 max |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Voltage Required | AC 120/230 V |
| 80 PLUS Certification | 80 PLUS Silver |
| Included Accessories |
Mounting screws 4 mounting ears 4 bumper feet Cable tie |
| Regulatory Standards |
CISPR 22 Class A CISPR 24 IEC 61000 series ICES-003 Class A UL 60950-1 CSA C22.2 No. 60950-1 VCCI Class A IEC 60825-1 EN 55022, EN 55024 FCC CFR47 Part 15A |
| Software Included |
Command Line Interface (CLI) HP Web Browser Interface HP Intelligent Management Center |
| Width | 17.4 in |
| Depth | 12 in |
| Height | 1.7 in |
| Weight | 8.6 lb |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
