| Manufacturer | Cisco |
| Product Line | Catalyst 9300 Series |
| Product Type | Stackable Access Switch |
| Ports | 48x Cisco UPOE (10/100/1000 Copper) |
| License | Network Advantage (Sibling C9300-48U-E is Network Essentials, Same Hardware) |
| Sibling | C9300-48P-A, PoE+ at 437W |
| Default Power Supply | PWR-C1-1100WAC-P (1100W AC) |
| PoE Budget | 822W (Up To 60W Per Port) |
| ASIC | UADP 2.0 |
| Uplink Module Options | C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-2Y (Modular, Sold Separately) |
| Switching Capacity | 256 Gbps |
| Forwarding Rate | 154.76 Mpps |
| Stacking | StackWise-480, Up To 480 Gbps, Up To 8 Units, StackPower Supported |
| DRAM | 8GB |
| Flash | 16GB Plus External USB 3.0 SSD Slot |
| MAC Address Table | 32,000 |
| IPv4 Routes (ARP Plus Learned) | 32,000 (24,000 Direct + 8,000 Indirect) |
| IPv6 Routing Entries | 16,000 |
| Multicast Routing Scale | 8,000 |
| QoS/ACL Scale Entries | 5,120 Each |
| Packet Buffer | 16MB |
| VLAN IDs | 4,094 |
| Switched Virtual Interfaces (SVIs) | 2,000 |
| Jumbo Frames | 9,198 Bytes |
| Total Routed Ports Per Stack | 208 |
| Wireless Bandwidth Per Switch | Up To 96 Gbps |
| MTBF | 299,000 Hours |
| Form Factor | 1U Rack Mountable |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
