| Brand | Juniper |
| Model | QFX10002-72Q |
| Form Factor | Fixed 2U core/spine |
| QSFP+ Ports (40GbE) | 72 |
| 100GbE QSFP28 Capable Ports | 24 (every third port) |
| Port Capacity | 288 x 10GbE, 72 x 40GbE, 24 x 100GbE |
| Breakout | Any 40G port as 4 x 10GbE |
| Throughput | 5.76 Tbps |
| Power Supplies | 4 x 1600 W AC or DC, factory installed |
| Fan Modules | 3, two fans each |
| Airflow | Front-to-back (port-to-FRU) |
| Typical Power Consumption | 1050 W (3,583 BTU/hr) |
| Maximum Power Consumption | 1425 W (4862 BTU/hr) |
| Routing Engine CPU | Quad-core Intel, 2.5 GHz |
| Routing Engine Memory | 16 GB |
| Storage | 2 x 25 GB SSD |
| Management Ports | 1 x RJ-45 1000BASE-T, 1 x SFP |
| Console Port | RJ-45 (RS-232) |
| USB Ports | 1 |
| Operating System | Junos OS |
| Dimensions (H x W x D) | 3.46 x 17.36 x 31 in (8.8 x 44.1 x 78.7 cm) |
| Weight (AC, FRUs installed) | 68.6 lb (31.1 kg) |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Relative Humidity | 5% to 90%, noncondensing |
| Altitude | Up to 6000 ft (1828.8 m) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
