| System capacity | PTX10003 8 Tbps PTX10003 16 Tbps |
| Slot Capacity | N/A |
| Chassis per rack | 14 |
| Dimensions (W x H x D) | PTX10003 8 Tbps: 17.4 x 5.25 x 31 in (44.2 x 13.3 x 78.7 cm) PTX10003 16 Tbps: 17.4 x 5.25 x 31 in (44.2 x 13.3 x 78.7 cm) |
| Maximum weight | PTX10003 8 Tbps: 88 lb (40 kg) PTX10003 16 Tbps: 110 lb (50 kg) |
| Mounting | Front rack mount |
| Power System Rating (Max) | PTX10003 8 Tbps: 2500 W (AC, DC), 8525 BTU/hr PTX10003 16 Tbps: 4000 W (AC, DC) 13,640 BTU/hr |
| Operating temperature | 32° to 115° F (0° to 46° C) |
| Humidity | Relative humidity operating: 5 to 90% (noncondensing) |
| Altitude | Up to 10,000 ft (3048 m) |
| 10G/40G/100G/200G/400G | PTX10003 8 Tbps: 160/40/80/32/16 PTX10003 16 Tbps: 320/80/160/64/32 |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
