| Manufacturer | Juniper |
| Product Line | MPC7E Series, MX Series |
| Product Type | Fixed-Configuration Modular Line Card |
| Ports | 12x QSFP+ (Default 10GbE, Configurable to 40GbE) |
| 100GbE-Capable Port Positions | 4 of 12 (Ports 0/2, 0/5, 1/2, 1/5) via QSFP28 Transceivers |
| Breakout Support | 40GbE Ports Break Out to 4x10GbE via Breakout Cable |
| Chipset | Junos Trio |
| Licensed Ports (Base RTU Model) | 6 (2x QSFP28) Ready For Use Out Of The Box |
| Layer 2/2.5 | Full-Scale Features |
| Layer 3 Scale (Base) | Reduced Scale — Up To 2 Million Routes (FIB), 6 Million Routes (RIB) |
| L3VPN Instances | Up To 32 Per Card |
| Aggregate Throughput Per 6-Port Group | Up To 240 Gbps (Max 480 Gbps Total Across Both Groups) |
| Line-Rate Throughput (MX960/480/240) | Up To 480 Gbps |
| Line-Rate Throughput (MX2000) | Up To 400 Gbps (SFB) / 430 Gbps (SFB2) |
| Required Network-Services Mode | Enhanced-IP or Enhanced-Ethernet |
| Chassis Requirements | High-Capacity Power Supplies, High-Capacity Fan Trays, SCBE2 or SCBE3 Switch Control Boards |
| MTU (Transit / Host-Bound) | 256-16,000 Bytes / 256-9,500 Bytes |
| Power Consumption | 440W (25°C) / 465W (40°C) / 545W (55°C) |
| Weight | 15.7 lb (7.12 kg) |
| Thermal Restriction (MX960) | Slot 11 Cannot Host This Card Above 55°C at Sea Level |
| LEDs | OK/FAIL Bicolor, Per-Port LINK (4 Per QSFP+ Cage) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
