Model | JL682A |
Product name | Aruba 6100 48G Class4 PoE 4SFP+ 740W Switch |
Device type | Layer 2+ Managed Gigabit Ethernet Switch |
Ports | 24x 10/100/1000BASE-T PoE+ ports, 4x 1/10G SFP+ uplinks |
PoE budget | 740W total PoE power (Class 4 PoE+) |
Switching capacity | 176 Gbps |
Throughput | 130.9 Mpps |
Management | Aruba Central, Web GUI, CLI, SNMP, REST API |
Layer 2 features | VLANs, STP, LACP, IGMP snooping, QoS |
Layer 3 features | Static and RIP routing, ACLs, DHCP relay |
Power supply | Internal AC power supply, 740W max |
Dimensions (H x W x D) | 1.73 x 17.42 x 11.85 in (4.4 x 44.25 x 30.1 cm) |
Weight | 10.45 lb (4.74 kg) |
Operating temperature | 0°C to 45°C (32°F to 113°F) |
Humidity | 10% to 90% non-condensing |
Mounting | 1U rack-mountable |
Security features | 802.1X, RADIUS, TACACS+, port security, ACLs |
Warranty | Limited Lifetime Warranty |
