| Manufacturer | Cisco |
| Product Line | 550X Series |
| Product Type | Stackable Managed Switch |
| Network Ports | 46x 10GBase-T Copper |
| Uplink Ports | 2x Combo (10GBase-T Copper or SFP+, One Active at a Time) |
| Management Port | 1x Dedicated Gigabit Ethernet (Out-of-Band) |
| Switching Capacity | 960 Gbps |
| Forwarding Rate | 714.24 Mpps |
| MAC Address Table | 32,000 |
| IPv4 Routing | Up To 7,168 Routes, 256 IP Interfaces |
| IPv6 Routing | Up To 1,792 Routes, 256 IPv6 Interfaces |
| VLANs | Up To 4,094 |
| ACL Entries | Up To 2,000 |
| Jumbo Frames | Up To 9,000 Bytes (Default MTU 2,000) |
| Stacking | Up To 8 Units, Up To 400 Ports Total, Hardware Failover |
| CPU | 800MHz Dual-Core ARM |
| CPU Memory | 512MB |
| Flash | 256MB |
| Packet Buffer | 4MB (Dynamically Shared) |
| Console Port | RJ-45 |
| USB | 1x Type-A |
| Power Consumption | 264.4W (110V) / 255.8W (220V) |
| Heat Dissipation | 902.17 BTU/hr |
| Cooling | 4+1 Redundant Fans |
| Acoustic Noise | 44.5 dB (0-25°C) / 58.9 dB (50°C) |
| MTBF (At 50°C) | 111,323 Hours |
| Operating Temperature | 32 to 122°F (0 to 50°C) |
| Storage Temperature | -4 to 158°F (-20 to 70°C) |
| Humidity | 10 to 90% Non-Condensing |
| Dimensions (W x H x D) | 17.3 x 1.7 x 17.72 in |
| Weight | 16.38 lb (7.43 kg) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
