| Brand | Cisco |
| Model | IE-3100-18T2C-E |
| Series | Catalyst IE3100 Rugged |
| Total Ports | 20 x Gigabit Ethernet |
| Copper Ports | 18 x 10/100/1000 |
| Combo Uplink Ports | 2 x Gigabit Ethernet combo |
| PoE | Not applicable |
| Forwarding Rate | 29.76 Mpps (64-byte packets) |
| Forwarding Bandwidth | 20 Gbps |
| Number of Queues | 8 egress |
| Unicast MAC Addresses | 8000 |
| IGMP Multicast Groups | 512 |
| VLANs | 256 |
| IPv4 Indirect Routes | 2000 |
| STP Instances | 128 |
| DRAM | 4 GB |
| Flash (User Accessible) | 1.5 GB |
| SD Card | Optional, sold separately (1 GB, 4 GB or 16 GB) |
| Alarm Inputs | 2 dry-contact alarm inputs |
| Console Ports | 1 RS-232 (via RJ-45), 1 Micro USB |
| Power Inputs | Dual DC inputs |
| Input Voltage Range | 12 to 48 VDC nominal, 9.6 to 60 VDC absolute |
| Redundancy Protocols | REP, MRP, Fast MRP, G.8032 ERP |
| Time Synchronization | PTP, NTP to PTP |
| Industrial Protocols | EtherNet/IP (CIP), Modbus, PROFINET MRP, GOOSE, SCADA protocol classification |
| Layer 2 and Layer 3 | 802.1Q, RSTP, MSTP, PVRST+, LACP, LLDP, inter-VLAN routing, static routing |
| Security | HTTPS, SSH, RADIUS, TACACS+, X.509v3, IP Source Guard, DHCPv6 Guard |
| Height | 5.00 in (12.70 cm) |
| Width | 4.30 in (10.92 cm) |
| Weight | 2.8 lb (1.27 kg) |
| Mounting | DIN rail |
| Operating Temperature | -40 to 167°F (-40 to 75°C) in a blower-equipped cabinet |
| Storage Temperature | -40 to 185°F (-40 to 85°C) |
| Relative Humidity | 5% to 95%, noncondensing |
| Operating Altitude | Up to 15,000 ft (4,572 m) with no temperature derating |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
