| Manufacturer | Cisco |
| Product Line | ASR 1000 Series |
| Product Type | Embedded Services Processor |
| Throughput Class | 100 Gbps |
| Processor Silicon | Third-Generation QuantumFlow Processor (QFP) |
| Sibling | ASR1000-ESP100 — CPP-Based, Older Generation, 29 Gbps IPsec (vs. 133 Gbps on This Module) |
| Sibling | ASR1000-ESP200-X — 200 Gbps Tier, 183 Gbps IPsec, Taller Chassis Slot |
| Compatible Chassis | ASR 1006-X, ASR 1009-X, ASR 1013 |
| Required Route Processor | ASR1000-RP3 |
| Memory | 32GB Cisco FP Resource Memory, 16GB DRAM, 80-Mb TCAM, 1.4GB Packet Buffer |
| Forwarding Rate | Up To 80 Mpps (Variable, Feature-Dependent) |
| IPsec Bandwidth | Up To 133 Gbps (Plain Encryption, 1400-Byte Packets) |
| ACL Scale | Up To 4,000 Unique ACLs, 380,000 IPv4 ACEs |
| IP Routes | Up To 4,000,000 IPv4 or IPv6 Routes |
| Multicast | Up To 100,000 Routes, 44,000 Groups |
| QoS Queues | Up To 232,000, 3 Hierarchy Levels |
| Firewall Sessions | Up To 16,000,000 |
| NAT Sessions | Up To 16,000,000, 100,000 Setup Rate/Sec |
| Carrier-Grade NAT | Up To 32,000,000 Sessions |
| IPsec Tunnels | Up To 8,000 |
| L3VPN | Up To 8,000 VRF Instances |
| GRE Tunnels | Up To 4,000 |
| Redundancy | 1+1 With Second Module, OIR, NSF/SSO, ISSU Support |
| Power Consumption | 415W Maximum, 285W Typical |
| Dimensions (H x W x D) | 0.92 x 16.7 x 14.19 in |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
