| Feature | Specification |
| Chassis | ASR 9001-S |
| Integrated interfaces | 2 x 10 Gigabit Ethernet SFP by default; the remaining 2 x 10 Gigabit Ethernet SFP ports can be activated by applying licenses |
| Modular port adapters | 20 x 1 Gigabit Ethernet, 2 x 10 Gigabit Ethernet, 4 x 10 Gigabit Ethernet, and 1 x 40 Gigabit Ethernet |
| Redundancy | Power supply redundancy |
| Power supply part number | ●A9K-750W-AC ●A9K-750W-DC |
| Physical specifications | ●Height: 3.472 in. (88.2 mm) ●Width: 17.42 in. (442 mm) ●Depth: 18.5 in. (470 mm) ●Weight of chassis: 30.2032 lbs (13.7 kg) ●Weight of chassis with two MPAs: 36.37623 lbs (16.5 kg) |
| Power inputs | ●Worldwide ranging AC (90-265V; 50-60 Hz) ●Worldwide ranging DC (-40V to -72V) |
| Power consumption | 375 W typical, 425 W maximum |
| Environmental conditions | ●Operating temperature: 32 to 104°F (0 to 40°C) ●Storage temperature: -40 to 167°F (-40 to 75°C) ●Relative humidity: 10 to 90%, noncondensing ●Regulatory compliance |
| Environmental Specifications | |
| Operating temperature (nominal) | 41 to 104ºF (5 to 40ºC) |
| Operating temperature (short-term) | 23 to 131ºF (-5 to 55ºC) |
| Operating humidity (nominal) (relative humidity) | 10 to 85% |
| Operating humidity (short-term) | 5 to 90% Note: Not to exceed 0.024 kg water or dry air |
| Storage temperature | -40 to 158ºF (-40 to 70ºC) |
| Storage (relative humidity) | 5 to 95% Note: Not to exceed 0.024 kg water or dry air |
| Operating altitude | -1800m |
| Air flow | Side to side |
| Compliance | |
| Network Equipment Building Standards (NEBS) | Cisco ASR 9001-S is designed to meet: ●SR-3580: NEBS Criteria Levels (Level 3) ●GR-1089-CORE: NEBS EMC and Safety ●GR-63-CORE: NEBS Physical Protection ●VZ.TPR.9205: Verizon TEEER |
| ETSI standards | Cisco ASR 9001-S is designed to meet (qualification in progress): ●EN300 386: Telecommunications Network Equipment (EMC) ●ETSI 300 019 Storage Class 1.1 ●ETSI 300 019 Transportation Class 2.3 ●ETSI 300 019 Stationary Use Class 3.1 ●EN55022: Information Technology Equipment (Emissions) ●EN55024: Information Technology Equipment (Immunity) ●EN50082-1/EN-61000-6-1: Generic Immunity Standard |
| EMC standards | Cisco ASR 9001-S is designed to meet: ●FCC Class A ●ICES 003 Class A ●AS/NZS 3548 Class A ●CISPR 22 (EN55022) Class A ●VCCI Class A ●BSMI Class A ●IEC/EN 61000-3-2: Power Line Harmonics ●IEC/EN 61000-3-3: Voltage Fluctuations and Flicker ●EN 50121-4: Railway EMC |
| Immunity | Cisco ASR 9001-S is designed to meet: ●IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ●IEC/EN-61000-4-3: Radiated Immunity (10V/m) ●IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ●IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ●IEC/EN-61000-4-5: Signal Ports (1kV) ●IEC/EN-61000-4-5: Surge DC Port (1kV) ●IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ●IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ●IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations ●EN 50121-4: Railway EMC |
| Safety | Cisco ASR 9001-S is designed to meet: ●UL/CSA/IEC/EN 60950-1 ●IEC/EN 60825 Laser Safety ●ACA TS001 ●AS/NZS 60950 ●FDA: Code of Federal Regulations Laser Safety |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
