| Device Type | Serial adapter |
|---|---|
| Form Factor | External |
| Interface (Bus) Type | USB |
| Ports | RS-422/485 |
| Connectivity Technology | Wired |
| Data Link Protocol | RS-422 RS-485 |
| Data Transfer Rate | 921.6 Kbps |
| Features | USB powered 2 KV Optical Isolation Protection |
| Compliant Standards | USB 1.1 USB 2.0 |
| Interfaces | 1 x RS-422/485 - terminal block |
| Cables Included | 1 x USB cable - 3.3 ft |
| MTBF | 159037 hours |
| Compliant Standards | EN55022 Class B EN 61000-6-1 EN 61000-4-4 EN 61000-4-2 EN 61000-4-3 EN 61000-4-6 IEC 60529 IP30 |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows 2000 Microsoft Windows Vista (32/64 bits) Microsoft Windows 7 (32/64 bits) Microsoft Windows XP (32/64 bits) Microsoft Windows Server 2008 (32/64-bits) Microsoft Windows Server 2003 (32/64-bits) |
| Width | 3.5 in |
| Depth | 1.7 in |
| Height | 0.8 in |
| Weight | 6.74 oz |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
