| Device Type | Expansion module |
| Form Factor | Rack-mountable |
| Ports | Gigabit Ethernet x 48 10 Gigabit SFP x 4 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 100Base-TX Ethernet 1000Base-T |
| Data Link Protocol | Fast Ethernet Gigabit Ethernet |
| Auxiliary Ports | 4 x SFP (uplink) |
| Performance | Forwarding performance (full duplex): 80 Gbps ¦ Forwarding performance: 176 Gbps ¦ Forwarding performance: 131 Mpps |
| Capacity | ACL entries: 256 ¦ Policies: 64 |
| Remote Management Protocol | SNMP 1 SNMP 2 RMON SNMP 3 CLI |
| Status Indicators | Port status power system module locator fan |
| Features | Flow control full duplex capability auto-negotiation VLAN support Cisco Gigabit EtherChannel Syslog support Weighted Round Robin (WRR) queuing Spanning Tree Protocol (STP) support Access Control List (ACL) support Quality of Service (QoS) Jumbo Frames support Management Information Base (MIB) Class of Service (CoS) tagged VLAN Virtual PortChannel (vPC) technology hot swappable power supply |
| Compliant Standards | IEEE 802.3 IEEE 802.3u IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3x IEEE 802.3ae IEEE 802.3an |
| Expansion Slots | 4 (total) / 4 (free) x SFP |
| Interfaces | 48 x 1000Base-T - RJ-45 |
| Compliant Standards | CISPR 22 Class A CISPR 24 EN 61000-3-2 EN 61000-3-3 EN55024 EN55022 Class A EN50082-1 EN 61000-6-1 AS/NZS 60950-1 ICES-003 Class A FCC CFR47 Part 15 UL 60950-1 IEC 60950-1 EN 60950-1 RoHS CSA C22.2 No. 60950-1 Directive 2004/108/EC Directive 2006/95/EC VCCI Class A CNS 13438(95) Class A KN22 Class A EN 300 386 GB 4943.1-2011 |
| Power Device | Power supply - hot-plug / redundant - plug-in module |
| Width | 17.3 in |
| Depth | 17.7 in |
| Height | 1.7 in |
| Weight | 17.64 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
