| Software compatibility | ● Cisco Collaboration Endpoint (CE) Software Version 9.14.5 or later, or Webex RoomOS |
| Default components in Room Kit Pro bundle | ● Webex Codec Pro ● Webex Quad Camera ● Webex Room Navigator ● Wall mount for Quad Camera |
| Default components in Room Kit Pro PTZ 4K integrator bundle | ● Webex Codec Pro ● Webex PTZ 4K Camera ● Webex Room Navigator |
| Optional hardware components | ● Cisco Table Microphone (with Euroblock plug), Cisco Ceiling Microphone, wall mount for Codec Pro, rack mount for Codec Pro, various cables |
| Bandwidth | ● Up to 6 Mbps point-to-point |
| Minimum bandwidth for resolution/frame rate | ● 720p30 from 768 kbps ● 720p60 from 1152 kbps ● 1080p30 from 1472 kbps ● 1080p60 from 2560 kbps |
| Firewall traversal | ● Cisco Expressway Technology H.460.18, H.460.19 firewall traversal |
| Video standards | ● H.264, H.265, H.263 for TANDBERG MXP interop only (check Admin Guide) |
| Video inputs (6) | ● 2 HDMI inputs support formats up to maximum 1080p60 ● 3 HDMI inputs support formats up to maximum UHD (3840 x 2160) @ 30 fps including HD1080p60 ● One 3G-SDI/HD-SDI input supports formats up to maximum 1080p60 ● Extended Display Identification Data (EDID) ● Consumer Electronics Control (CEC) 2.0 |
| Video outputs (3) | ● 2 HDMI outputs support formats up to 3840 x 2160@60 fps (4Kp60) ● 1 HDMI output supports formats up to 3840 x 2160@30 fps (4Kp30) ● CEC 2.0 |
| Encode and decode | ● Video stream: Full HD 1080p60 ● Content stream: 4K 2160p15 |
| Audio standards | ● G.711, G.722, G.722.1, G.729AB, 64 kbps and 128 kbps MPEG4 AAC-LD mono and stereo, OPUS |
| Audio features | ● High quality 20-kHz audio ● 8 separate acoustic echo cancellers ● 8-port audio mixer ● 8 assignable equalizers ● Automatic Gain Control (AGC) ● Automatic noise reduction ● Active lip synchronization |
| Audio inputs | ● 8 microphones, 48V phantom powered, Euroblock connector, each with separate echo cancellers and noise reduction; all microphones can be set for balanced line level ● 3 HDMI, digital: stereo PC/DVD input ● Bluetooth ® - Not available on Non Radio Version * |
| Audio outputs | ● 6 balanced line level outputs, Euroblock connector ● 3 HDMI outputs ● HDMI input #1 supports Audio Return Channel (ARC) audio output to Quad Camera ● 1 line out for subwoofer (Quad Camera) ● Bluetooth ® - Not available on Non Radio Version * |
| Speakers (Quad Camera) | ● High-quality speakers ● Frequency response 70 Hz to 20 kHz ● Max output level SPL 90 dB |
| Speaker tracking (Quad Camera, SpeakerTrack 60) | ● Quad Camera offers 6-element microphone array for accurate speaker tracking ● Quad Camera can support Group Framing feature with 5x zoom capability ● SpeakerTrack 60 can support Closeup feature with 20x zoom capability |
| PresenterTrack (PTZ 4K Camera, Precision 60) | ● AI-powered face and upper body detection capability ● Camera automatically follows the active presenter within a defined zone and helps ensure optimized view |
| Dual stream | ● H.239 (H.323) dual stream ● BFCP Session Initiation Protocol (SIP) dual stream ● Supports resolutions up to 3840 x 2160p15 fps and 1080p60 |
| Wireless sharing | ● Webex clients (up to 3840 x 2160p5) ● Cisco Intelligent Proximity client (up to 1920 x 1080p5) ● Miracast (1080p30) – Not available on Non radio version * |
| Multipoint support | ● 5-way embedded SIP/H.323 conferencing capability with MultiSite option |
| MultiSite features (embedded multipoint) (optional upgrade) | ● Adaptive SIP/H.323 MultiSite: ◦ 3-way resolution up to 1080p30 plus content up to 4Kp15 ◦ 4-way resolution up to 720p30 plus content up to 4Kp15 ◦ 5-way resolution up to 720p30 plus content up to 4Kp15 ● Full individual audio and video transcoding ● H.323, SIP, and VoIP in the same conference ● Support for presentation (H.239, BFCP) from any participant at resolutions up to 3840 x 2160p5 ● Best impression (automatic continuous presence layouts) ● Encryption and dual stream from any site |
| Protocols | ● H.323 ● SIP ● Webex |
| Embedded encryption | ● H.323 and SIP point-to-point ● Standards-based: H.235 v3 and Advanced Encryption Standard (AES) ● Automatic key generation and exchange |
| IP network features | ● DNS lookup for service configuration ● Differentiated Services (DiffServ) (Quality of Service [QoS]) ● IP-adaptive bandwidth management (including flow control) ● Automatic gatekeeper discovery ● Dynamic playout and lip-sync buffering ● H.245 dual-tone multifrequency (DTMF) tones in H.323 ● DTMF tones in SIP, RFC 4733 ● Date and time support using Network Time Protocol (NTP) ● Packet loss-based down speeding ● Uniform Resource Identifier (URI) dialing ● TCP/IP ● Dynamic Host Configuration Protocol (DHCP) ● 802.1X network authentication ● 802.1Q Virtual LAN ● 802.1p QoS and class of service ● Cisco Media Assure and ClearPath |
| Call control | ● Cisco Collaboration Cloud / Webex ● Cisco Unified Communications Manager (CUCM) ◦ Native registration CUCM ◦ Requires CUCM Version 10.5.2 or later with device pack for Room Kit Pro ● Cisco TelePresence Video Communication Server (VCS) ◦ Native registration with VCS ● Third-party H.323 gatekeepers and standards-based SIP proxies |
| IPv6 network support | ● Single call stack support for both H323 and SIP ● Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ ● Support for static IP address assignment, stateless auto-configuration, and DHCP v6 |
| Security features | ● Management using HTTPS and SSH ● IP administration password ● Password to access administration features on Touch controller ● Disable IP services ● Network settings protection |
| Certificate management | ● Certificate Authority Proxy Function (CAPF) support for additional security ● Manufacturer-Installed Certificates (MIC) ● Locally Significant Certificates (LSC) ● X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported |
| Network interfaces Codec Pro | ● 1 Ethernet (RJ-45) 10/100/1000 for LAN ● 2 Ethernet (RJ-45) 10/100/1000 for direct pairing with camera (camera control) ● 2 Ethernet (RJ-45) 10/100/1000 with PoE, 1 dedicated for direct pairing with Touch 10 ● Wi-Fi 802.11a/b/g/n/ac 2.4 GHz and 5 GHz for LAN - not available in non-radio versions ● 2x2 multiple input and multiple output (MIMO) Note: Due to compliance regulations, it is required that 802.11d is enabled in the access point for the product to operate properly within 5725 MHz – 5875 MHz. Using a Wifi connection is a flexible option, however an Ethernet connection is always preferred for high performance. |
| Other interfaces | ● 2x USB A port, USB-B, micro USB port, factory reset pinhole |
| Power supply (Quad Camera) | ● 100 to 240 VAC, 50/60 Hz, 12V DC input ● Standby 6W, average 20W, peak 70W |
| Operating temperature and humidity | ● 0° to 40°C (32° to 104°F) ambient temperature ● 10% to 90% Relative Humidity (RH) |
| Storage and transport temperature | ● -20° to 60°C (-4° to 140°F) at RH 10% to 90% (noncondensing) |
| Dimensions | Codec Pro: ● Width: 17.1 in. (43.6 cm) ● Height: 2.6 in. (6.6 cm) ● Depth: 9.1 in. (23.1 cm) ● Weight: 7.3 lb (3.3 kg) Quad Camera: ● Width: 37.4 in. (95.0 cm) ● Height: 4.7 in. (12.0 cm) ● Depth: 4.0 in. (10.3 cm) ● Weight: 10.6 lb (4.8 kg) Dimensions for other available cameras: ● PTZ 4K Camera: ◦ Width: 6.3 in. (15.8 cm) ◦ Height (at max tilt): 7.0 in. (17.7 cm) ◦ Depth: 8.0 in. (20.0 cm) ◦ Weight: 3.75 lb (1.7 kg) ● Precision 60 Camera: ◦ Length: 10.6 in. (26.8 cm) ◦ Height (at max. tilt): 7.1 in (18 cm) ◦ Depth: 6.4 in. (16.3 cm) ◦ Weight: 5.5 lb. (2.5 kg) SpeakerTrack 60 Camera: ● Length: 31.5 in. (80.0 cm) ● Height: 11.5 in. (29.2 cm) ● Depth: 8.3 in. (21.0 cm) ● Weight: 25.4 lb (11.5 kg) |
